Creasing matrix, steel rule, ejection rubber, gap filler sponge, brass and magnesium stamping dies, silicone pads and mounting tape. MOQ from 1 die, samples free.
Post-Press Consumables
Creasing matrix, steel rule, ejection rubber and sponge, stamping and embossing dies, silicone pads and mounting tape for die-cutting and foil stamping lines.
Post-Press Consumables — browse and filter products
Creasing MatrixAP-PM PVC Creasing Matrix for Die-Cutting
PVC-base self-adhesive creasing matrix in standard, narrow, wider, off-centre and double-crease profiles for crack-free folds.
View Details
Creasing MatrixAP-RM Resin, Fibre & Pressboard Creasing Matrix
Harder-wearing resin, fibre, PET and pressboard creasing matrix grades for long runs on automatic die-cutters.
View Details
Creasing MatrixAP-RB Reverse Bend Creasing Matrix
Reverse bend matrix for folds that must close against the printed side without cracking the coating.
View Details
Creasing MatrixAP-CR Creasing Matrix in Coils
Continuous-coil creasing matrix for long straight scores and high-volume die-shop consumption.
View Details
Die-Cutting ConsumablesAP-SR Steel Rule Cutting Blade for Die Boards
Hardened steel rule for cutting and creasing die boards — consistent bevel, straight running, long edge life.
View Details
Ejection Rubber & SpongeAP-WS Die-Cutting Ejection Wave Sponge
Colour-coded high-elastic wave sponge in 35°–65° hardness, 380 × 300 mm sheets, 8/9/10/12 mm heights.
View Details
Ejection Rubber & SpongeAP-SS Seam Sponge Strip & Gold Cushion
65° seam sponge strip in 1–8 mm widths plus 75° gold cushion for the narrow, high-pressure areas of a die board.
View Details
Ejection Rubber & SpongeAP-RS Functional Rubber Strips for Die-Cutting
Arched rubber, anti-back-pressure, corrugated protection, air-permeable and cork strips for problem areas on a die board.
View Details
Stamping & Embossing DiesBrass & Magnesium Hot Stamping Dies
Engraved brass and magnesium stamping dies made to your artwork — the tooling that decides foil edge quality.
View Details
Stamping & Embossing DiesEmbossing & Debossing Dies
Matched male and female die sets for blind embossing, debossing and combination foil-and-emboss finishing.
View Details
Stamping & Embossing DiesSilicone Rubber Pad for Hot Stamping
Heat-resistant silicone pads that carry foil onto curved, textured and uneven surfaces without flattening them.
View Details
Auxiliary ConsumablesPlate Mounting Double-Sided Tape
Foam and film double-sided tape for mounting stamping dies, embossing plates and flexo sleeves in register.
View DetailsAll-in Pack supplies the consumables that keep die-cutting and foil stamping running — creasing matrix, steel rule, ejection rubber, gap filler sponge, brass and magnesium dies, silicone pads and mounting tape — matched to the board, the tool and the press rather than sold from a fixed list.
Post-Press Consumables We Supply
Consumables decide make-ready time and edge quality far more than machine brand. These are the families we stock and cut to order.
- Creasing matrix — fibre-reinforced, channel widths 0.9–2.0 mm and heights 0.3–0.6 mm on 25 m self-adhesive rolls.
- Steel rule — cutting, creasing and perforating rule at 23.8 mm height in 2pt, 3pt and 4pt thickness.
- Ejection rubber — closed-cell profiles from 25 to 45 Shore 00 in strip, block and chamfered shapes.
- Gap filler sponge — 2–6 mm widths for narrow waste channels where a full profile will not fit.
- Hot stamping and embossing dies — CNC-engraved brass, photo-etched magnesium and matched male/female emboss sets.
- Silicone rubber pads and plate mounting tape for curved work and in-register tool fixing.
How to Choose by Board, Rule and Run Length
Specify consumables from the board calliper and the run length. Most crease cracking and blank-lifting problems trace back to a mismatched channel or the wrong rubber hardness.
- Folding boxboard 250–400 gsm — 1.0–1.4 mm channel with 0.4 mm matrix height.
- Heavy board and micro-flute — wider channel plus firm 35–45 Shore 00 ejection rubber.
- Fine detail and long runs — brass dies; short runs and prototypes — magnesium.
- Curved, grained or soft-touch surfaces — silicone pad between die and workpiece.
- Narrow waste areas — 2–4 mm gap filler sponge instead of a standard profile.
MOQ, Lead Time and Tooling Turnaround
Stock consumables ship from inventory; dies are cut to your artwork with a proof impression before shipment.
- MOQ: 10 rolls or strips for consumables, 1 piece for dies.
- Lead time: 7–12 days for stock items, 5–7 days for magnesium dies, 10–18 days for brass and emboss sets.
- Artwork: AI, EPS, PDF or CDR vector; we return a die layout for approval.
- Shipping: FOB Ningbo/Shanghai, express air for urgent tooling.
- Samples: free consumable sample kits and a proof impression on your substrate.
Request Consumable Samples or a Tooling Quote
Send the board grade, rule height, press model and artwork, and we specify the matrix, rubber and die set and quote within 24 hours.
Frequently Asked Questions
- Can you cut hot stamping dies from our artwork?
- Yes. Send vector artwork (AI, EPS, PDF or CDR) with the press model and we return a die layout for approval, then ship magnesium dies in 5–7 days or brass dies in 10–15 days with a proof impression.
- How do I choose the creasing matrix channel width?
- Channel width follows board calliper and rule thickness — 1.0–1.4 mm channel with 0.4 mm height covers most 250–400 gsm folding boxboard. Send the board grade and rule height and we ship the matching profile with a fitting chart.
- What is the minimum order for consumables?
- 10 rolls or strips per profile for matrix, rubber, sponge and tape, and a single piece for dies. Free sample kits are available so you can test hardness and channel fit before ordering volume.
