    All-in Pack (AllinPacks®) — stamping foils, self-adhesive materials and post-press equipment supplier
    All-in Pack®
    Large coil roll of AP-CR continuous creasing matrix tape with the grooved channel feeding out
    AP-CR coil-supplied creasing matrix — cut to any length without joins.

    Quick answer

    AP-CR Creasing Matrix in Coils is a Post-Press Consumables product manufactured and exported by All-in Pack (Wenzhou, China), used for Large-format folding cartons, Corrugated shelf-ready packaging, Rigid box blanks. Core specification: Model Series AP-CR (coil creasing matrix), Material PVC standard; resin / fibre on request. It ships FOB Shanghai with MOQ from one roll, 5–14 day lead times on stock items, free A4 samples and Pantone colour matching on request.

    Creasing Matrix

    AP-CR Creasing Matrix in Coils

    Key specifications at a glance

    • Channel Width: 0.9 / 1.0 / 1.2 / 1.4 / 1.6 / 2.0 mm
    • Coil Length: 25 m / 50 m
    • Material: PVC standard; resin / fibre on request
    • Channel Height: 0.3 / 0.4 / 0.5 / 0.6 mm
    • Rule Height: 23.8 mm standard formes
    • Packaging: Individually boxed coils, 10 per carton
    • MOQ: 10 coils

    Continuous-coil creasing matrix for long straight scores and high-volume die-shop consumption.

    Key Features

    • Continuous coil — no joins on long scores
    • Same channel widths and heights as the strip range
    • Lower cost per metre for high-consumption die shops
    • High-tack acrylic self-adhesive base
    • Cuts cleanly with standard matrix shears
    • PVC standard; resin and fibre bodies on request

    Overview

    Boxed strips are convenient for jobbing work, but a die shop making formes all day wastes material on off-cuts and joins. Coil-supplied matrix is cut to any length, so a 1,200 mm score is one continuous piece instead of three strips with two joins that can show in the fold.

    Where coils pay back

    Long straight scores on large-format cartons, corrugated shelf-ready packaging and rigid box blanks. Same channel geometry and sizing rules as the strip range; the resin and fibre bodies from the AP-RM series are also available in coil form on request.

    Technical Specifications

    Model SeriesAP-CR (coil creasing matrix)
    MaterialPVC standard; resin / fibre on request
    Channel Width0.9 / 1.0 / 1.2 / 1.4 / 1.6 / 2.0 mm
    Channel Height0.3 / 0.4 / 0.5 / 0.6 mm
    Coil Length25 m / 50 m
    Rule Height23.8 mm standard formes
    AdhesiveHigh-tack acrylic base
    PackagingIndividually boxed coils, 10 per carton

    Ordering & Procurement

    Sourcing facts buyers ask for first — confirmed per specification when we quote.

    Minimum order
    10 coils
    Price range
    USD 8–20 per coil (FOB)
    Certifications
    ISO 9001 production, RoHS declaration on request
    Shipping terms
    FOB Ningbo / Shanghai
    Lead time
    10–15 days
    Samples
    Free 1 m sample lengths

    Applications

    Large-format folding cartonsCorrugated shelf-ready packagingRigid box blanksDie shops producing formes in volumeLong straight scores

    Frequently Asked Questions

    What are the key features of AP-CR Creasing Matrix in Coils?

    Continuous coil — no joins on long scores. Same channel widths and heights as the strip range. Lower cost per metre for high-consumption die shops. High-tack acrylic self-adhesive base. Cuts cleanly with standard matrix shears. PVC standard; resin and fibre bodies on request.

    What are the typical applications of AP-CR Creasing Matrix in Coils?

    AP-CR Creasing Matrix in Coils is widely used in: Large-format folding cartons, Corrugated shelf-ready packaging, Rigid box blanks, Die shops producing formes in volume, Long straight scores.

    What are the technical specifications of AP-CR Creasing Matrix in Coils?

    Key specifications include — Model Series: AP-CR (coil creasing matrix); Material: PVC standard; resin / fibre on request; Channel Width: 0.9 / 1.0 / 1.2 / 1.4 / 1.6 / 2.0 mm; Channel Height: 0.3 / 0.4 / 0.5 / 0.6 mm; Coil Length: 25 m / 50 m; Rule Height: 23.8 mm standard formes.

    What is the minimum order quantity (MOQ) for AP-CR Creasing Matrix in Coils?

    MOQ for AP-CR Creasing Matrix in Coils is flexible and depends on specification, width and color. Please contact our sales team via the Request a Quote form for an exact MOQ tailored to your project.

    What is the typical lead time and shipping for AP-CR Creasing Matrix in Coils?

    Standard lead time is 7–15 working days for in-stock items and 20–35 days for custom production. All-in Pack ships globally via sea, air and express couriers (DHL, FedEx, UPS) from our facilities in China.

    Can I get free samples of AP-CR Creasing Matrix in Coils?

    Yes — free A4-size samples of AP-CR Creasing Matrix in Coils are available for qualified business buyers. Submit a quote request and our team will arrange sample dispatch within 2 working days.
