Paper Cutting Machines
QZK-1370 Hydraulic Paper Cutting Machine
The QZK-1370 is a high-precision hydraulic paper cutting machine with programmable digital backgauge for accurate, repeatable cuts. Features dual hydraulic cylinders, safety light curtain, and infrared alignment for efficient paper, cardboard, and board trimming.
Key Features
- Max cutting width: 1370mm
- Programmable digital backgauge with 99 programs
- Dual hydraulic cylinder for even cutting pressure
- Safety light curtain and two-hand operation
- Infrared cutting line indicator
- Air table for easy sheet positioning
- HSS blade with 4-side rotation capability
Technical Specifications
| Max Cutting Width | 1370mm |
| Max Cutting Height | 165mm |
| Cutting Accuracy | ±0.3mm |
| Backgauge Stroke | 850mm |
| Cutting Force | 45 tons |
| Programs | 99 sets, 999 steps |
| Total Power | 5.5kW |
| Machine Weight | 3,000kg |
Applications
Print shop paper trimmingPackaging board cuttingLabel stock sheetingPhoto & poster trimmingCardboard processing
